HERE IS SOME OF THE EQUIPMENT WE USE AT ALLUSION FM


THE EQIPMENT ABOVE IS THE OLD ALLUSION FM SET UP AS THE TRANSMITTER ABOVE NOW BELONGS TO THE DTI
WE AT ALLUSION FM HAVE TWO STUDIOS THAT WE CAN USE ONE IS THE PC
WHEN USING THE PC WE USE A PROGRAME CALLED PCDJ



Front view of transmitter
the new 100 watt pll transmitter that we have bought for the allusion fm show
100 Watt Transmitter Specifications:


Type: VHF/FM PLL wideband modulation,
AC mains powered
Frequency Coverage: 87.0 to 110 MHz
Frequency Generation: frequency wideband osc/doubler
Frequency Correction: Phase Locked Loop Synth.
Frequency Stability: Plus/minus 1KHz (crystal controlled)
RF power out: 100 watts min
Harmonic Rejection: -50dB down
Spurious: -70dB down on carrier
S/N ratio: -80dB down on line level
Audio input: 0.775 V rms for +/- 75 KHz
Pre-emphasis: None, 50 uS, 75uS switchable
Unlock power down: lock detect with override test option
Audio performance: Less than 0.2% distortion, 20Hz-75KHz
Amplifier stage: MRF173/MRF174 single stage
PA efficiency: 80%
PA protection: Directional Coupler SWR monitor
LED indication: SWR, 28volt, Lock, Unlock
Cooling system: 92mm fan depression cooling
Supply Voltage required: 240Vac or 110Vac
Dimensions: 395w x 225d x 140h (mm)

Plug in the wall. lol. (back of transmitter)
Too buy this product it will cost 395 pound not including 17.5% v.a.t and tax
dj allusion and dj misschief on a night out lol as we DONT have many lol
audio input


dj allusion putting up areil
Dj Allusion putting up an ariel as usuall>>>>>>>>>>>>


WE WILL BE ADDING THE PICS OF THE ALLUSION TRANSMITTER WHEN WE RECIEVE IT ALLUSION FM WILL NEVER BE STOPPED
